八角形遮阳伞 LYBRA

倾斜杆回转支杆居中

Product overview
Turn the handle, the canopy tilts: Lybra is the octagonal garden parasol with EquiTilt® technology in the handle. The sun moves, the shade has to follow. Whether it’s a garden party, a dinner with friends by the pool or the Sunday family lunch: the shade follows the sun — adjust the tilt with a single motion.

Highlights

• EquiTilt® on the toothed handle: tilts the canopy, no external lever
• Acrishade 260 gsm fabric: UPF 50+, certified colour retention 1,500 hours
• Eight 14×20 mm aluminium ribs: canopy always taut
• Manual 360° rotation: shade in any direction

Key features and system

• Gradual EquiTilt®: rotating the knurled handle progressively tilts the canopy; infinite intermediate positions (no fixed click-stops).
• Opening by crank handle (easy open/close) + EquiTilt® function integrated into the knurled handle (two separated, complementary mechanisms).
• Aluminium structure: pole Ø 38 mm; eight commercial-grade aluminium ribs (14×20 mm) for stiffness and durability.
• Integrated top air vent (aerodynamic centre opening without flap) to release gusts and reduce pressure on the fabric.
• Exclusive Maanta Acrishade canopy: 260 gsm solution-dyed acrylic, water-repellent, UPF 50+, tested for lightfastness (1,500 h, grade 4).
• Manual 360° rotation of the pole in the base: direct the shade in any direction without moving the base.
• Modular accessories available (sold separately): several compatible bases, protective cover, magnetic LED lamp and clip-on LED lamp.

Product overview — practical notes

• Octagonal shape available in three diameters: 2.7 m, 3.0 m, 3.3 m.
• Headroom beneath canopy: approx. 204 cm (Ø 2.7), 198 cm (Ø 3.0), 200 cm (Ø 3.3).
• Net weight (parasol only): 6.8 kg (Ø 2.7), 7.7 kg (Ø 3.0), 8.7 kg (Ø 3.3).
• Wind resistance: up to 30 km/h (Beaufort 5) — for stronger conditions close and store the parasol.
• Parasol sold without anchoring base (base must be chosen and purchased separately).

Compatible accessories

• Protective cover (zip closure, 100% polyester) — protects canopy and frame when not in use.
• Magnetic 2-in-1 LED Light (Ø 278 mm, 2,500 mAh, dimmer) — magnetic mount for centre pole.
• Clip-on LED Lamp (alternative smaller lamp).
• Multiple base options: fillable resin base, concrete/steel bases, wheel-ready bases (all sold separately).

Caractéristiques / spécifications techniques

• Available sizes: Ø 2.7 m · Ø 3.0 m · Ø 3.3 m
• Opening and tilt: Crank opening · EquiTilt® on the handle (stepless, infinite positions) · 360° manual pole rotation
• Fabric: Acrishade 260 gsm, solution-dyed acrylic, UPF 50+, water-repellent, light fastness 1,500 h (grade 4)
• Frame: aluminium; 8 ribs 14×20 mm; pole Ø 38 mm
• Air vent: integrated top aerodynamic vent (no external flap)
• Headroom under canopy: 204 cm (Ø 2.7) · 198 cm (Ø 3.0) · 200 cm (Ø 3.3)
• Total height open (approx): 250 cm
• Height closed (approx): 107 cm (Ø 2.7) · 94 cm (Ø 3.0) · 80 cm (Ø 3.3)
• Net weight (parasol only): 6.8 kg (Ø 2.7) · 7.7 kg (Ø 3.0) · 8.7 kg (Ø 3.3)
• Gross weight / Box dimensions: gross weights ~8.5–10.5 kg depending on size; box 178 × 17 × 17 cm; shipping volume 0.051 m³
• Colours (canopy): Graphite · Vellum · Glacier · White · Terracotta · Wheat
• Frame finishes: Anthracite · Matt Anodizing · Matt White (preset aesthetic combinations available)
• Warranty: 2 years on frame · 2 years on Acrishade fabric
